MPN
PROZ690ADDR4
CPU (MAX SUPPORT)
i9
SOCKET
1700
CHIPSET
Intel Z690 Chipset
DDR4 MEMORY
5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz
MEMORY CHANNEL
Dual
DIMM SLOTS
4
MAX MEMORY (GB)
128
PCI-E X16
3
SATAIII
6
PCI-E X1
1
M.2 SLOT
4
RAID
0/1/5/10
TPM (HEADER)
1
LAN
1x Intel I225-V 2.5Gbps LAN
USB 3.2 PORTS (FRONT)
1(Gen 2, Type C), 4(Gen 1, Type A)
USB 3.2 PORTS (REAR)
1(Gen 2x2, Type C), 1(Gen 2, Type A), 2(Gen 1, Type A)
USB 2.0 PORTS (FRONT)
4
USB 2.0 PORTS (REAR)
4
AUDIO PORTS (REAR)
Realtek ALC897 Codec
DISPLAYPORT
1
HDMI
1
DIRECTX
12
FORM FACTOR
ATX
CROSSFIRE
Y
OPERATING SYSTEM
Support for Windows 11 64-bit, Windows 10 64-bit
