EVGA Power Supply 100-BR-0700-K1 700 BR 700W 80+BRONZE 12V PCI Express 120mm Long SleeveBearing Retail
EVGA Power Supply 100-BR-0700-K1 700 BR 700W 80+BRONZE 12V PCI Express 120mm Long SleeveBearing Retail
EVGA Power Supply 100-BR-0700-K1 700 BR 700W 80+BRONZE 12V PCI Express 120mm Long SleeveBearing Retail
EVGA Power Supply 100-BR-0700-K1 700 BR 700W 80+BRONZE 12V PCI Express 120mm Long SleeveBearing Retail
New
EVGA Power Supply 100-BR-0700-K1 700 BR 700W 80+BRONZE 12V PCI Express 120mm Long SleeveBearing Retail
EVGA Power Supply 100-BR-0700-K1 700 BR 700W 80+BRONZE 12V PCI Express 120mm Long SleeveBearing Retail
EVGA Power Supply 100-BR-0700-K1 700 BR 700W 80+BRONZE 12V PCI Express 120mm Long SleeveBearing Retail
EVGA Power Supply 100-BR-0700-K1 700 BR 700W 80+BRONZE 12V PCI Express 120mm Long SleeveBearing Retail

EVGA Power Supply 100-BR-0700-K1 700 BR 700W 80+BRONZE 12V PCI Express 120mm Long SleeveBearing Retail

$90.55
SHARE
CABLE LENGTH
ATX CABLE
1x 550mm
EPS CABLE
1x 600mm (m)
PCIE CABLE
2x 550mm, 670mm
SATA CABLE
3x 450mm, 570mm, 690mm
FOUR-PIN PERIPHERAL CABLE
1x 450mm, 570mm, 690mm + 810mm (Floppy)
AC POWER
1x 1200mm (m)
MODULAR CABLE TYPE
No
CONNECTOR QUANTITY
24 PIN ATX
1x
EPS (CPU)
1x 8pin (4+4)
PCIE
4x 8pin (6+2)
SATA
9x
FOUR-PIN PERIPHERAL
3x
FLOPPY
1x
POWER SPECS
AC Input
100 - 240 VAC, 10/5A, 50 - 60 Hz
Rail: +3.3V/Max Output: 24A/150W
Rail: +5V/Max Output: 20A/150W
Rail: +12V/Max Output: 58.3/ 699.6W/ 699.6W
Rail: +5Vsb/Max Output: 3A/ 15W
Rail: -12V/Max Output: 0.3A/3.6W
Total
700W at +30C
OPERATING TEMPERATURE
0o to 30o C
JAPANESE CAPACITORS
NO
ECO MODE
NO
MTBF
100,000 Hours
APPROVALS
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
FAN SIZE / BEARING
120mm Fluid Dynamic Bearing
