Supermicro Case CSE-835TQC-R802B 3U 800W 8x3.5
Supermicro Case CSE-835TQC-R802B 3U 800W 8x3.5
Out Of Stock
Supermicro Case CSE-835TQC-R802B 3U 800W 8x3.5
Supermicro Case CSE-835TQC-R802B 3U 800W 8x3.5

Supermicro Case CSE-835TQC-R802B 3U 800W 8x3.5"Hot-swap SAS3/SATA3 5xFan Black Brown Box

$1,169.99
SHARE
MPN
CSE-835TQC-R802B
Form Factor
3U chassis support for motherboard size - E-ATX and ATX.
Processor Support
Dual and Single Intel and AMD processors
Available Color
Black
Expansion Slots
7 full-height and full-length expansion slot(s)
Drive Bays
8 x 3.5" hot-swap SAS/SATA
Backplane
3U 8-Port Backplane Supports 8 x 3.5" SAS3/SATA3 HDD/SSD for X11 Platform
Peripheral Drives
1 x slim DVD-ROM drive bay
Front Panel
Buttons
Power On/Off button
System Reset Button
LEDs
2 Network Activity LEDs
HDD activity LED
Power LED
Power Fail LED
System Overheat LED
Systems Cooling
Fans
3 x 80mm Hot-swap PWM Fans
2 x 80mm rear hot-swap exhaust PWM fan(s)
System Monitoring
Chassis intrusion switch
Operating Environment (System)
Operating Temperature Range
5oC - 35oC (41oF - 95oF)
Non-Operating Temperature Range
-40oC - 70oC (-40oF - 158oF)
Operating Relative Humidity Range
8% - 90% (non-condensing)
Non-Operating Relative Humidity Range
5% - 95% (non-condensing)
Power Supply
1U 800W Redundant Power Supply 76mm width, W/PMbus, Titanium
Power Efficiency
96%
Total Output Power and Input
800W with Input 100 - 240Vac
800W with Input 200 - 240Vdc
AC Input Frequency
50-60Hz
Output Type
Backplanes (gold finger)
+12V
Max: 66A (100Vac - 240Vac)
Max: 66A (200 - 240)
+5Vsb
Max: 4A / Min: 0A
Power Distributor
PDB-PT825-8824
O/P: 12V/75
+5V Max: 30
+3.3V Max: 24
-12V Max: 0.6
Certification
Titanium Certified
Regulatory (Power Supply)
Power Supply Safety / EMC
BSMI
CCC
CE/EMC
FCC class A
TUV/CB
UL/CUL
