EVGA Power Supply 220-G5-1000-X1 1000 G5 1000W 80+GOLD Fully Modular FDB Fan Retail
EVGA Power Supply 220-G5-1000-X1 1000 G5 1000W 80+GOLD Fully Modular FDB Fan Retail
EVGA Power Supply 220-G5-1000-X1 1000 G5 1000W 80+GOLD Fully Modular FDB Fan Retail
EVGA Power Supply 220-G5-1000-X1 1000 G5 1000W 80+GOLD Fully Modular FDB Fan Retail
New
EVGA Power Supply 220-G5-1000-X1 1000 G5 1000W 80+GOLD Fully Modular FDB Fan Retail
EVGA Power Supply 220-G5-1000-X1 1000 G5 1000W 80+GOLD Fully Modular FDB Fan Retail
EVGA Power Supply 220-G5-1000-X1 1000 G5 1000W 80+GOLD Fully Modular FDB Fan Retail
EVGA Power Supply 220-G5-1000-X1 1000 G5 1000W 80+GOLD Fully Modular FDB Fan Retail

EVGA Power Supply 220-G5-1000-X1 1000 G5 1000W 80+GOLD Fully Modular FDB Fan Retail

$213.32
SHARE
MPN
220-G5-1000-X1
CABLE LENGTH
ATX Cable
1x 600mm (m)
EPS Cable
2x 700mm (m)
PCIe Cable
4x 700mm, 850mm (m)
SATA Cable
3x 550mm, 650mm, 750mm, 850mm (m)
Four-Pin Peripheral Cable
1x 550mm, 650mm, 750mm, 850mm (m)
Floppy Adapter
1x 100mm
AC Power
1x 1500mm (m)
Modular Cable Type
Full

CONNECTOR QUANTITY
24 Pin ATX
1x 24pin (20+4)
EPS (CPU)
2x 8pin (4+4)
PCIe
8x 8pin (6+2)
SATA
12x
Four-Pin Peripheral
4x
Floppy
1x

POWER SPECS
AC Input
100 - 240 VAC, 15-8A, 50/60 Hz
Rail
+3.3V
Max Output
24A
120W
Rail
+5V
Max Output
24A
120W
Rail
+12V
Max Output
83.3A
999.6W
999.6W
Rail
+5Vsb
Max Output
3A
15W
Rail
-12V
Max Output
0.5A
6W
Total
1000W at +50C

ADDITIONAL DETAILS
Operating Temperature
0o to 50oC
Japanese Capacitors
100%
ECO Mode
Yes
MTBF
100,000 Hours
Approvals
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 3 2014 Requirement
Fan Size / Bearing
135mm Fluid Dynamic Bearing
