EVGA Motherboard 121-VR-A579-KR X570 AM4 SATA 6Gb/s USB 3.2 Gen2x2 E-ATX Retail

MPN
121-VR-A579-KR
Specifications
Chipset AMD X570
SLI 2-Way SLI
SATA 8 Native SATA 6 Gb/s Ports
RAID 0, 1, 10
USB USB 2.0 (2 Internal Headers + SPI to USB Type-A)
Memory Support 2 DIMM Dual-Channel (up to 64GB) DDR4 4800MHz+
Capacitors 100% Solid State
Ethernet 2x Intel 2.5 Gigabit NIC
Audio Realtek ALC1220 7.1 Channel HD Audio + SV3H615
Fan Headers 8 (2x 3A Pump 2x CPU PWM, 4x PWM/DC)
PCB 10 Layers
PCI-E Slot Arrangement 2x16, 1x4
NVMe Support Yes (2x PCIe Gen4 + PCIe + SATA)
Form Factor
E-ATX Form Factor
Length: 12in - 304.8mm
Width: 10.89in - 276.6mm
Features
150% Increased Socket Gold Content
2-Way SLI Support
Built for EVGA ELEET X1
EVGA ELEET X1 Software Support
EVGA Probe-It Connector
EVGAs Latest GUI BIOS Featuring OC Robot and In-BIOS Stress Testing
Highly-Efficient 17 Phase Digital VRM
New Integrated EVGA Wireless Module with Intel Dual-band WiFi 6 / BT5.2 with external antenna
Onboard ARGB and RGB Headers controlled through EVGA ELEET X1
Onboard Clear CMOS, Power and Reset Buttons
Onboard Temperature and Voltage Monitoring
PCI Express Gen 4
PCIe Disable Switches
Realtek 7.1 Channel HD Audio + EVGA NU Audio
Reinforced PCIe slots
SafeBoot button resets the motherboard and goes into the BIOS with last known good settings without clearing CMOS
Slow Mode switch locks CPU multiplier to lowest possible setting to allow users to switch between max OC and low speeds in real-time.
SPI flashing via USB allows you to flash your BIOS without a CPU
Supports AMD AM4 Socket 1331 Processors
Triple BIOS Support
Operating System Support
Windows 10 64bit
