Synology Network Attachment Storage DX517 5bay Expansion Unit DX517 SATA Retail

MPN
DX517
Drive Bays
5
Compatible Drive Type
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
Maximum Internal Raw Capacity
50 TB (10 TB HDD x 5) (Capacity may vary by RAID types)
Hot Swappable Drive
Yes
RAID Management through Synology DSM
Yes
eSATA port
1
Power Recovery
Synchronized with the Synology DiskStation
Power Supply Unit / Adapter
200W
AC Input Power Voltage
100V to 240V AC
Power Frequency
50/60 Hz, Single Phase
Power Consumption
29.9 W (Access)
2.4 W (HDD Hibernation)
British Thermal Unit
102.02 BTU/hr (Access)
8.19 BTU/hr (HDD Hibernation)
Note
Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Operating Temperature
5C to 40C (40F to 104F)
Storage Temperature
-10C to 70C (15F to 155F)
Relative Humidity
5% to 95% RH
System Fan
80 mm x 80 mm x 2 pcs
Easy Replacement System Fan
Yes
Noise Level
21.5 dB(A)
Note
Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in idle Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear Background noise: 16.49-17.51 dB(A) Temperature: 24.25-25.75^oC Humidity: 58.2-61.8%
Certification
FCC Class B
CE Class B
BSMI Class B
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Cord X 1
Expansion Cable: eSATA X 1
Quick Installation Guide X 1
